Description
| Model | Working pressure (bar) |
Oil displacement per stroke (cm³) |
Reservior (cm³) |
Dimensions (mm) |
Packing size (cm) |
Weight (Kg) |
|||||
| Low pressure stage |
High pressure stage |
Low pressure stage |
High pressure stage |
Oil capacity |
Usable oil capacity |
L | B | H | |||
| HHB-700 | 20 | 700 | 13 | 1.6 | 970 | 950 | 600 | 120 | 200 | 73X19X19 | 10.6 |
| HHB-700A | 20 | 700 | 13 | 2.3 | 2750 | 2100 | 715 | 120 | 200 | 82X18X18 | 16.8 |
| HHB-700B | 20 | 700 | 13 | 2.3 | 970 | 900 | 600 | 120 | 240 | 75X18X27 | 12.4 |
| HHB-700C | 20 | 700 | 8 | 1 | 400 | 350 | 380 | 120 | 140 | 60X16X17 | 5.6 |
