Description
| Model | Pump type |
Working pressure (bar) |
Oil displacement per stroke (cm³) |
Reservior (cm³) |
Dimensions (mm) |
Packing size (cm) |
Weight (Kg) |
|||||
| Low pressure stage |
High pressure stage |
Low pressure stage |
High pressure stage |
Oil capacity |
Usable oil capacity |
L | B | H | ||||
| HHB-7000 | one-way | 20 | 700 | 126.2 | 4.75 | 7500 | 7000 | 740 | 310 | 330 | 83X38X35 | 26.5 |
| HHB-7000S | two-way | 20 | 700 | 126.2 | 4.75 | 7500 | 7000 | 740 | 310 | 330 | 83X38X35 | 27.5 |
